Han's Robot
Elfin E10-L
The Elfin E10-L is a long-reach 8 kg payload collaborative robot spanning 1300 mm, offering extended workspace coverage for larger-format assembly and material-handling tasks.
💲 Price on application
Full specifications
Performance
How much it lifts, how far it reaches, how precisely it repeats.
- Payload
Maximum mass the robot can carry at the wrist flange, including the gripper/tool. Higher means it can handle heavier parts.
- 8 kg 44th pct in class
- Reach
Maximum horizontal distance from the base axis to the wrist — defines the size of the work area. Higher means a larger envelope.
- 1,300 mm 60th pct in class
- Repeatability
How close the robot returns to the same taught point on repeated tries (ISO 9283, ±). Lower is better — tighter precision.
- 0.1 mm 0th pct in class
- Axes (DOF)
Number of independently driven joints / degrees of freedom. 6 is standard for articulated arms; 4 for SCARA/palletizers; 7 adds elbow redundancy.
- 6
Motion range & speed
Per-axis travel limits and rotational speeds.
Motion range and maximum speed per joint.
| Axis | Range | Max speed |
|---|---|---|
| J1 | -360° to 360° | 100 °/s |
| J2 | -360° to 360° | 100 °/s |
| J3 | -360° to 360° | 150 °/s |
| J4 | -360° to 360° | 150 °/s |
| J5 | -360° to 360° | 180 °/s |
| J6 | -360° to 360° | 180 °/s |
Physical
Size, mass and how it mounts.
- Robot weight
Mass of the manipulator (arm) without controller. Lighter eases mounting and mobile use; heavier often means stiffer/higher payload.
- 45 kg
- Mounting
Orientations the robot can be installed in (floor, ceiling/inverted, wall, tilted, mobile base).
- floor, ceiling, wall, any
Environment
Conditions it can operate in — dust, water, temperature, cleanliness.
- IP rating (arm)
Ingress protection of the body against dust/water (IEC 60529). First digit = dust, second = water. Higher resists harsher environments.
- IP54 5th pct in class
- Operating temp
Ambient temperature range for normal operation.
- 0 to 50 °C
Safety
Standards met and collaborative-operation capability.
- Collaborative
Whether the robot is designed to work safely next to people without fencing (power-and-force-limited).
- Yes
- Safety standards
Certified safety standards (ISO 10218-1, ISO/TS 15066) and functional-safety level (PLd/PLe, SIL2/3).
- ISO 10218-1, ISO/TS 15066
- Cert. cobot payload
Payload at which collaborative (force-limited) operation is still certified.
- 8 kg 43th pct in class
Control & software
Programming, languages and ecosystem.
- Programming
How the robot is taught: pendant, hand-guiding (lead-through), block/flow-chart, scripting, offline simulation.
- hand-guiding, graphical
- ROS support
Robot Operating System driver availability (none / ROS 1 / ROS 2 / both).
- ros1
- Offline programming
Whether programs can be built and validated offline in a digital twin before deployment.
- Yes
Connectivity & I/O
Signals, fieldbuses and tooling interfaces.
- Fieldbus
Industrial networks supported for PLC/cell integration (PROFINET, EtherNet/IP, EtherCAT, Modbus TCP, CC-Link, etc.).
- EtherCAT, Modbus, PROFINET
- Digital I/O
Built-in digital inputs/outputs for grippers, sensors and signalling.
- 16 in / 16 out
- Analog I/O
Built-in analog inputs/outputs.
- 2 in / 2 out
- Integrated vision
Whether a camera / vision system is built into the robot or controller.
- No
Industrial Robotics Hub — industrialroboticshub.com
Safety certifications
- ISO 10218-1 — the primary industrial-robot safety standard covering design and construction requirements
- ISO/TS 15066 — the safety standard for collaborative robots working near people (force and speed limits)
Specifications sourced from Han's Robot official datasheet ↗. Specs last verified 2026-06-26.
Owner reviews
Real, first-hand feedback from people who run the Han's Robot Elfin E10-L. Sign in with LinkedIn so we know reviews come from actual operators. You choose whether to post under your name or anonymously.
We only read your name, photo and headline. Posting anonymously hides all of that from public view.
Frequently asked questions
What is the payload of the Han's Robot Elfin E10-L? +
The Han's Robot Elfin E10-L has a maximum payload of 8 kg.
What is the reach of the Han's Robot Elfin E10-L? +
The Han's Robot Elfin E10-L has a maximum reach of 1,300 mm (1.30 m).
What is the repeatability of the Han's Robot Elfin E10-L? +
The Han's Robot Elfin E10-L has a pose repeatability of ±0.1 mm (ISO 9283), making it suitable for precision work.
How many axes does the Han's Robot Elfin E10-L have? +
The Han's Robot Elfin E10-L is a 6-axis collaborative robot.
What is the Han's Robot Elfin E10-L used for? +
The Han's Robot Elfin E10-L is typically used for assembly, material-handling, machine-tending.
Is the Han's Robot Elfin E10-L a collaborative robot? +
Yes — the Han's Robot Elfin E10-L is a collaborative robot (cobot) designed to work safely alongside people under ISO/TS 15066.
What is the IP rating of the Han's Robot Elfin E10-L? +
The Han's Robot Elfin E10-L arm carries an IP54 ingress-protection rating.
How much does the Han's Robot Elfin E10-L cost? +
Han's Robot Elfin E10-L: Price on application. Industrial robots are typically quoted per project through authorized distributors.
